MidNite Solar MNEPV5-150-1PNP 5 Amps Din Rail Mount Breaker
MidNite Solar MNEPV5-150-1PNP 5 Amps Din Rail Mount Breaker
Couldn't load pickup availability
MidNite's breakers are rated to break the full rated load at the rated voltage repeatedly, with NO DAMAGE. Always use a properly sized breaker for disconnecting. All MidNite circuit breakers can be used at 100% rated current when mounted in a MidNite enclosure. Breaker Torque Value: 20 In-Lbs (2.3NM).
5 Amps
NON POLARIZED
Environmental Rating - Type 1 (Indoor)
DC Voltage Rating - 150VDC
Wire Size Range - 14 to 6 AWG
Width - 0.5 inches (13mm)
Number of poles - 1
Listed for US & Canada
10,000 AIC
